1D / 2D / PDF417

Aiming pattern:650nm visible laser diode, Illumination:630nm LED

DS3578 only: 2200 mAh Lithium Ion Battery (note that DS3508 does not require a battery)

USB, RS-232, RS-485 (IBM 46xx Protocols), Keyboard Wedge

1D : UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/ JAN-8/JAN-13 plus supplementals, ISBN (Bookland), ISSN, Coupon Code), Code 39 (Standard, Full ASCII , Trioptic), Code 128 (Standard, Full ASCII, UCC/EAN-128, ISBT-128 Concatenated), Code 93, Codabar/ NW7, Code 11 (Standard, Matrix 2 of 5), MSI Plessey, I 2 of 5 (Interleaved 2 of 5 / IT F, Discrete 2 of 5, IATA , Chinese 2 of 5), GS1 DataBar (Omni-directional, Truncated, Stacked, Stacked Omni-directional, Limited, Expanded, Expanded Stacked, Inverse), Base 32 (Italian Pharmacode)

2D : TL C-39, Aztec (Standard, Inverse), MaxiCode, DataMatrix/ECC 200 (Standard, Inverse), QR Code (Standard, Inverse, Micro)

PDF417 : PDF417 (Standard, Macro), microPDF417 (Standard, Macro), Composite Codes (CC-A, CC-B, CC-C)

Code 39 - 7.5 mil [Near:21.6 cm / Far:34 in./86.4 cm]
Code 39 - 10 mil [Near : 20.3 cm / Far:42 in./106.7 cm]
Code 39 - 20 mil [Near : * / Far:88 in./223.5 cm]
Code 39 - 55 mil [Near : * / Far:205 in./520.7 cm]
Code 39 - 100 mil [Near : * / Far:335 in./851.0 cm]

• 산업 환경
• 실내/실외
• 창고형 소매점
